| Fattore Di Forma |
ATX |
| Sockel |
Intel 1851 (LGA1851) |
| Chipsatz |
Intel Z890 |
| Compatibilità Cpu |
Core Ultra 200S,Elenco compatibilità CPU |
| Ram |
4x slot DIMM DDR5, doppio canale, max. UDIMM da 256 GB non ECC |
| Velocità Dati Ram |
DDR5-5600 UDIMM/?DDR5-6400 CUDIMM (Core Ultra 200S), max. DDR5-8800OC |
| Ecc-Unterstützung |
nein |
| Accessori Esterni |
1x DisplayPort 2.1 (HDCP 2.3, iGPU), 1x USB4 con DisplayPort 2.1 (40Gb/?s, PD-Out, HDCP 2.3, iGPU), 1x USB-A 3.1 (10Gb/?s), 4x USB-A 3.0 (5Gb/?s), 4x USB-A 2.0 (480Mb/?s), 3x 3.5mm Klinke (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG), 2x Antennenanschluss Quick Connect |
| Slot Pcie |
1x PCIe 5.0 x16, 3x PCIe 4.0 x16 (2x x4, 1x x1) |
| Slot M.2 |
1x M.2/?M-Key (PCIe 5.0 x4, 25110/?2580/?22110/?2280), 1x M.2/?M-Key (PCIe 4.0 x4, 25110/?2580/?22110/?2280), 1x M.2/?M-Key (PCIe 4.0 x4/?SATA, 25110/?2580/?22110/?2280), 1x M.2/?E-Key (2230, collegato con modulo WiFi+BT) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (Z890) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.0 Key-A (5 Gb/?s, 1x USB-C), 1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x connettore TPM, 1x connettore seriell, 1x connettore Thunderbolt a 5 pin, 1x connettore per scheda GIGABYTE USB4 (THB_U4) |
| Anschlüsse Intern - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 1x CPU-Lüfter/?Pumpe 4-Pin PWM, 2x CPU-Lüfter 4-Pin PWM, 2x CPU-Lüfter/?Pumpe 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 2x EPS12V a 8 pin |
| Anschlüsse Stagista - Beleuchtung |
1x RGB a 4 pin (+12V/?G/?R/?B, max. 2A), 3x ARGB a 3 pin (+5V/?DATA/?GND, max. 3A, GIGABYTE Gen2) |
| Pulsanti/Interruttori |
Pulsante di accensione (interno), pulsante di ripristino (interno), USB BIOS Flashback/?Q-Flash Plus (interno) |
| Audio |
Realtek ALC897 |
| Rete |
Realtek RTL8125BG (2,5Gb/?s) |
| Grafica |
iGPU |
| Livello Raid |
0/?1/?5/?10 (Z890) |
| Senza Fili |
Wi-Fi 6E (WLAN 802.11a/?b/?g/?n/?ac/?ax, 2x2), Bluetooth 5.3 (Intel AX211 o Realtek RTL8852CE) |
| Vrm-Design |
12+1+2, 13 fasi CPU virtuali (2x6+1), 7 fasi CPU reali (6+1) |
| Mosfet Vcore |
12x 60A |
| Mosfet Soc/Vccgt |
1x |
| Mosfet Sonstige |
2x |
| Beleuchtung |
N/?D |
| Bios |
1x 32MB (256Mb) |
| Besonderheiten |
Condensatori audio+solidi, LED diagnostico (indicatore LED), 1x M.2-Passivkühler |
| Garanzia |
3 anni (Informazioni) |
| Usb-Schreibweise |
Link |
| Aggiornamento Anticipato |
28-01-2026, 17:47 |
| Gelistet Set |
2024-10-10, 10:51 |
