| Fattore Di Forma |
?ATX |
| Sockel |
Intel 1700 (LGA1700) |
| Chipsatz |
Intel B760 |
| Compatibilità Cpu |
Celeron G6000,Pentium Gold G7000,Core i-12000,Core i-13000,Core i-14000,Elenco compatibilità CPU |
| Ram |
4x slot DIMM DDR5, doppio canale, max. UDIMM da 256 GB non ECC |
| Velocità Dati Ram |
DDR5-4800 (Celeron G6000/?Pentium Gold G7000/?Core i-12000), DDR5-4800/?DDR5-5600 (Core i-13000/?Core i-14000) |
| Ecc-Unterstützung |
nein |
| Accessori Esterni |
2x DisplayPort 1.2 (HDCP 2.3, iGPU), 1x HDMI 2.1 TMDS (HDCP 2.3, iGPU), 1x VGA (iGPU), 1x USB-C 3.1 (10Gb/?s), 3x USB-A 3.0 (5Gb/?s), 2x USB-A 2.0 (480 Mb/?s), 3x Klinke da 3,5 mm (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125D), 1x PS/?2 Combo |
| Slot Pcie |
1x PCIe 5.0 x16, 2x PCIe 3.0 x1 |
| Slot M.2 |
2x M.2/?M-Key (PCIe 4.0 x4, 2280) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (B760) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x intestazione seriell, 1x intestazione parallela, 1x intestazione TPM, 1x intestazione S/?PDIF |
| Anschlüsse Intern - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 3x Lüfter 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 1x EPS12V a 8 pin |
| Anschlüsse Stagista - Beleuchtung |
1x RGB a 4 pin (+12V/?G/?R/?B, max. 2A), 2x ARGB a 3 pin (+5V/?DATA/?GND, max. 3A, GIGABYTE Gen2) |
| Pulsanti/Interruttori |
USB BIOS Flashback/?Q-Flash Plus (stagista) |
| Audio |
Realtek ALC897 |
| Rete |
Realtek RTL8125D (2,5Gb/?s) |
| Grafica |
iGPU |
| Livello Raid |
0/?1/?5/?10 (B760) |
| Vrm-Design |
6+2+1, 8 fasi CPU virtuali (6+2), 8 fasi CPU reali (6+2) |
| Mosfet Vcore |
6x 46A 4C10N/?12x 4C06N (High-/?Low-Side) |
| Mosfet Soc/Vccgt |
2x 46A 4C10N/?4C06N (High-/?Low-Side) |
| Mosfet Sonstige |
1x |
| Controller Pwm |
NCP81530R (max. 10 fasi) |
| Beleuchtung |
N/?D |
| Bios |
1x 16MB (128Mb) |
| Besonderheiten |
Condensatori audio+solidi, 1x M.2-Passivkühler |
| Garanzia |
3 anni (Informazioni) |
| Usb-Schreibweise |
Link |
| Aggiornamento Preliminare Ufficiale |
2026-01-13, 14:32 |
| Gelistet Set |
2025-08-14, 14:12 |
