| Fattore Di Forma |
?ATX |
| Sockel |
AMD AM5 |
| Chipsatz |
AMD B650 |
| Compatibilità Cpu |
Ryzen 7000,Ryzen 8000G,Ryzen 9000,Elenco compatibilità CPU |
| Ram |
4x slot DIMM DDR5, doppio canale, max. UDIMM da 256 GB non ECC |
| Velocità Dati Ram |
DDR5-5200 (Ryzen 7000/?Ryzen 8000G), DDR5-5600 (Ryzen 9000), max. DDR5-7200OC |
| Ecc-Unterstützung |
nein |
| Accessori Esterni |
1x DisplayPort 1.4 (iGPU), 1x HDMI 2.1 (iGPU), 1x USB-C 3.1 (10Gb/?s), 3x USB-A 3.1 (10Gb/?s), 4x USB-A 3.0 (5Gb/?s), 3x 3,5 mm Klinke (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG), 2x connettori per antenne RP-SMA |
| Slot Pcie |
1x PCIe 4.0 x16, 2x PCIe 3.0 x1 |
| Slot M.2 |
2x M.2/?M-Key (PCIe 4.0 x4, 2280/?2260), 1x M.2/?E-Key (2230, collegato con modulo WiFi+BT) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (B650) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.1 Key-A (10 Gb/?s, 1x USB-C), 1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x TPM Header, 1x Chassis Intrusion Header, 1x MSI Tuning Controller Header Header (MSI JDASH) |
| Anschlüsse Intern - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 3x Lüfter 4-Pin PWM, 1x Pumpe 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 2x EPS12V a 8 pin |
| Anschlüsse Intern - Beleuchtung |
2x RGB a 4 pin (+12V/?G/?R/?B, max. 3A), 2x ARGB a 3 pin (+5V/?DATA/?GND, max. 3A, MSI JARGB_V2) |
| Pulsanti/Interruttori |
Flashback BIOS USB (esterno) |
| Audio |
Realtek ALC897 |
| Rete |
Realtek RTL8125BG (2,5Gb/?s) |
| Grafica |
iGPU |
| Senza Fili |
Wi-Fi 6E (WLAN 802.11a/?b/?g/?n/?ac/?ax, 2x2), Bluetooth 5.3 |
| Livello Raid |
0/?1/?10 (B650) |
| Vrm-Design |
10+2, 12 fasi CPU virtuali (2x5+2), 7 fasi CPU reali (5+2) |
| Mosfet Vcore |
10x 55A SM4337/?SM4503 (High-/?Low-Side) |
| Mosfet Soc/Vccgt |
2x 55 A SM4337/?4x SM4503 (High-/?Low-Side) |
| Controller Pwm |
RT3678BE (max. 10 fasi) |
| Beleuchtung |
N/?D |
| Bios |
1x 32MB (256Mb) |
| Besonderheiten |
Condensatori solidi+audio, LED diagnostico (indicatore LED), I/?O-Blende integriert, 2x M.2-Passivkühler |
| Garanzia |
3 anni (Informazioni) |
| Usb-Schreibweise |
Link |
| Aggiornamento Preliminare Ufficiale |
2026-01-13, 14:32 |
| Gelistet Set |
2024-03-04, 11:51 |
