| Fattore Di Forma |
?ATX |
| Sockel |
AMD AM5 |
| Chipsatz |
AMD B840 |
| Compatibilità Cpu |
Ryzen 7000,Ryzen 8000G,Ryzen 9000,Elenco compatibilità CPU |
| Ram |
4x slot DIMM DDR5, doppio canale, max. UDIMM da 256 GB non ECC |
| Velocità Dati Ram |
DDR5-5200 (Ryzen 7000/?Ryzen 8000G), DDR5-5600 (Ryzen 9000), max. DDR5-8200OC |
| Ecc-Unterstützung |
nein |
| Anschlüsse Extern |
2x DisplayPort 1.4 (iGPU), 1x HDMI 2.1 (HDCP 2.3, iGPU), 1x USB-C 3.0 (5Gb/?s), 2x USB-A 3.0 (5Gb/?s), 4x USB-A 2.0 (480Mb/?s), 3x 3.5mm Klinke (Realtek ALC897), 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG), 1x PS/?2 Combo, 2x Antenna RP-SMA |
| Slot Pcie |
1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4) |
| Slot M.2 |
1x M.2/?M-Key (PCIe 4.0 x4, 2580/?2280), 1x M.2/?M-Key (PCIe 4.0 x4, 25110/?2580/?22110/?2280), 1x M.2/?E-Key (2230, collegato con Modulo WiFi+BT) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (B840) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.0 Key-A (5 Gb/?s, 1x USB-C), 1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x intestazione TPM |
| Anschlüsse Intern - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 1x CPU-Lüfter/?Pumpe 4-Pin PWM, 1x CPU-Lüfter 4-Pin PWM, 1x CPU-Lüfter/?Pumpe 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 1x EPS12V a 8 pin |
| Anschlüsse Stagista - Beleuchtung |
2x ARGB a 3 pin (+5V/?DATA/?GND, max. 3A, GIGABYTE Gen2), 1x RGB a 4 pin (+12V/?G/?R/?B, max. 2A) |
| Pulsanti/Interruttori |
USB BIOS Flashback/?Q-Flash Plus (esterno) |
| Audio |
Realtek ALC897 |
| Rete |
Realtek RTL8125BG (2,5Gb/?s) |
| Grafica |
iGPU |
| Livello Raid |
0/?1/?10 (B840) |
| Senza Fili |
Wi-Fi 6 (WLAN 802.11a/?b/?g/?n/?ac/?ax, 2x2, Realtek RTL8851BE), Bluetooth 5.3 |
| Design Vrm |
8+2+2, 10 fasi CPU virtuali (8+2) |
| Mosfet Vcore |
8x |
| Mosfet Soc/Vccgt |
2x |
| Mosfet Sonstige |
2x |
| Beleuchtung |
N/?D |
| Bios |
1x 32MB (256Mb) |
| Besonderheiten |
Condensatori audio+solidi, LED diagnostico (indicatore LED), 1x M.2-Passivkühler |
| Garanzia |
3 anni (Informazioni) |
| Usb-Schreibweise |
Link |
| Aggiornamento Preliminare Ufficiale |
28-01-2026, 17:46 |
| Gelistet Set |
2025-09-12, 11:47 |
