| Fattore Di Forma |
?ATX |
| Sockel |
AMD AM5 |
| Chipsatz |
AMD B850 |
| Compatibilità Cpu |
Ryzen 7000,Ryzen 8000G,Ryzen 9000,Elenco compatibilità CPU |
| Ram |
2x slot DIMM DDR5, doppio canale, max. UDIMM da 128 GB non ECC+ECC |
| Velocità Dati Ram |
DDR5-5200 (Ryzen 7000/?Ryzen 8000G), DDR5-5600 (Ryzen 9000), max. DDR5-8400OC |
| Ecc-Unterstützung |
ja |
| Collegamento Esterno |
1x DisplayPort 1.4 (iGPU), 1x HDMI 2.1 (iGPU), 2x USB-A 3.1 (10Gb/?s), 2x USB-A 3.0 (5Gb/?s), 4x USB-A 2.0 (480Mb/?s), 3x 3.5mm Klinke (Realtek), 1x RJ-45 (2.5GBase-T, Realtek), 1x PS/2 Combo |
| Slot Pcie |
1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4) |
| Slot M.2 |
1x M.2/?M-Key (PCIe 5.0 x4, 2280), 1x M.2/?M-Key (PCIe 4.0 x4, 2280/?2260/?2242) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (B850) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.0 Key-A (5 Gb/?s, 1x USB-C), 1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x intestazione seriell, 1x intestazione S/?PDIF, 1x intestazione TPM |
| Anschlüsse Intern - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 3x Lüfter 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 1x EPS12V a 8 pin |
| Anschlüsse Stagista - Beleuchtung |
3x ARGB a 3 pin (+5V/?DATA/?GND, max. 3A, ASUS Gen2) |
| Pulsanti/Interruttori |
Flashback BIOS USB (esterno) |
| Audio |
Realtek |
| Rete |
Realtek (2,5Gb/?s) |
| Grafica |
iGPU |
| Livello Raid |
0/?1/?10 (B850) |
| Design Vrm |
8+2+1, 10 fasi CPU virtuali (8+2) |
| Mosfet Vcore |
8x 58A SiRA14BDP/?SiRA12BDP (High-/?Low-Side) |
| Mosfet Soc/Vccgt |
2x 58A SiRA14BDP/?4x SiRA12BDP (High-/?Low-Side) |
| Mosfet Sonstige |
1x 58A SiRA14BDP/?SiRA12BDP (High-/?Low-Side) |
| Controller Pwm |
ASP2308 (XDPE12284C, max. 8 fasi), RT3672EE (max. 2 fasi) |
| Beleuchtung |
N/?D |
| Bios |
1x 32MB (256Mb) |
| Besonderheiten |
Condensatori audio+solidi, Bianco Build-compatibel (PCB primimär schwarz), 1x M.2-Passivkühler |
| Garanzia |
3 anni |
| Usb-Schreibweise |
Link |
| Aggiornamento Precedente Letztes |
2026-01-13, 13:43 |
| Gelistet Set |
2025-04-11, 14:17 |
