| Fattore Di Forma |
?ATX |
| Sockel |
AMD AM4 |
| Chipsatz |
AMD B550 |
| Compatibilità Cpu |
Ryzen 3000,Ryzen 4000G,Ryzen 5000,Ryzen 5000G,Elenco compatibilità CPU |
| Ram |
4x slot DIMM DDR4, doppio canale, max. UDIMM da 128 GB non ECC+ECC |
| Velocità Dati Ram |
DDR4-3200 (Ryzen 3000/?Ryzen 4000G/?Ryzen 5000/?Ryzen 5000G), max. DDR4-4866OC |
| Ecc-Unterstützung |
ja |
| Collegamento Esterno |
1x HDMI 2.1 (iGPU), 1x VGA (iGPU), 1x DVI-D (iGPU), 2x USB-A 3.1 (10Gb/?s, PCH), 4x USB-A 3.0 (5Gb/?s), 3x 3.5mm Klinke (Realtek ALC887), 1x RJ-45 (1000Base-T, Realtek RTL8111H), 1x PS/?2 combinato |
| Slot Pcie |
1x PCIe 4.0 x16, 2x PCIe 3.0 x1 |
| Slot M.2 |
1x M.2/?M-Key (PCIe 4.0 x4/?SATA, 22110/?2280/?2260/?2242), 1x M.2/?M-Key (PCIe 3.0 x4/?SATA, 2280/?2260/?2242) |
| Sonstige Schnittstellen |
4x SATA 6Gb/s (B550) |
| Anschlüsse Stagista - Usb |
1x Header USB 3.0 a 20 pin (5 Gb/?s, 2x USB-A), 2x Header USB 2.0 a 9 pin (480 Mb/?s, 4x USB-A) |
| Anschlüsse Intern - Sonstige |
1x intestazione seriell, 1x intestazione TPM, 1x intestazione S/?PDIF, 1x intestazione altoparlante, 1x intestazione COM Debug |
| Anschlüsse Stagista - Kühlung |
1x CPU-Lüfter 4-Pin PWM, 2x Lüfter 4-Pin PWM |
| Anschlüsse Stagista - Stromversorgung |
1x ATX a 24 pin, 1x EPS12V a 8 pin |
| Stagista Anschlüsse - Beleuchtung |
N/?A |
| Audio |
Realtek ALC887 |
| Rete |
Realtek RTL8111H (1Gb/?s) |
| Grafica |
iGPU |
| Livello Raid |
0/?1/?10 (B550) |
| Vrm-Design |
3+4, 7 fasi CPU virtuali (3+2x2), 5 fasi CPU reali (3+2) |
| Mosfet Vcore |
3x 58A SiRA14DP/?6x SiRA12DP (High-/?Low-Side) |
| Mosfet Soc/Vccgt |
4x 58A SiRA14DP/?SiRA12DP (High-/?Low-Side) |
| Controller Pwm |
ASP1106 (RT3667BE, max. 6 fasi) |
| Beleuchtung |
N/?D |
| Bios |
1x 32MB (256Mb) |
| Besonderheiten |
Condensatori audio+solidi, Bianco compatibile con la costruzione (PCB inizialmente nero) |
| Garanzia |
3 anni |
| Usb-Schreibweise |
Link |
| Aggiornamento Anticipato |
2026-01-13, 13:42 |
| Gelistet Set |
2020-05-25, 12:20 |
